Seating and stowage
A further view of 787-derived cabin features on the 747-8.
The 747-8 cabin showing its seating configuration and overhead bins.
The stowage that made the ceiling
The bins are the 787’s contribution. On the 777 the centre bins are built into the ceiling curve; on the 747-8 they are shaped to appear suspended from it, leaving the arch visible along the full length of the cabin. The result is the piece of 747-8 styling passengers touch: bigger, curved, opening bins that read as continuous ceiling rather than as a row of lockers.
Main deck seating is typically 3-4-3 in economy — the standard 747 count that seats ten across — while the economics of a 467-seat aircraft decide the pitch. What the layout gains over a 747-400 is space, not just seats.
Below the floor, the 747-8’s cargo capacity is a third greater than the 747-400’s — partly because the crew rest area moved upstairs. Add the 787-derived lighting and windows, and the interior the render describes is the last real cabin evolution of the 747: overhead-bin arch, LED mood lighting, and floors finished however each airline chose.
For the seat-map view of how operators actually sold this cabin, see the Lufthansa 747-8 layout.
